Frameless Glass Partitions
Minimalist floor-to-ceiling glass wall systems utilizing heavy-duty clear or low-iron glass panels held in recessed perimeter tracks, giving maximum light transmission and seamless spatial flow.
Factory Direct Glazing Systems
Architectural Glass Partition Manufacturing for Overseas Procurement & UAE Contractors
Delivering certified safety glass, acoustic control partitions, and extruded aluminium profile walls engineered to international building standards (BS EN 12150, ASTM C1048) directly from our 20,000+ sq. ft. fabrication facility in Al Sajaa.
Certified Tempered Glass
Machined using 10mm to 12mm heat-soaked tempered safety glass or PVB laminated acoustic glass with polished edges and precision CNC cut-outs for door ironmongery.
Acoustic Attenuation
Integrated acoustic gasket seals and double-glazed wall profiles providing certified sound reduction up to STC 42 dB for executive cabins, boardrooms, and private meeting suites.
Extruded Aluminium Frame
High-grade 6063-T6 architectural aluminium track systems finished in anodic anodising, textured powder coatings, or custom RAL shades matching global project specs.
System Portfolio
Comprehensive Office & Commercial Glass Wall Configurations
Engineered for high-volume commercial office fit-outs, luxury villa interiors, hospitality spaces, and international export contracts.
Office & Executive Cabins
Modular glass wall partitions engineered for rapid jobsite assembly, featuring frameless or framed glass swing doors, hydraulic patch fittings, and soft-closing overhead sliding gear.
Acoustic Double-Glazed Partitions
Dual-pane acoustic wall partitions engineered for corporate spaces requiring total confidentiality. Built with sound-dampening acoustic PVB interlayers and perimeter sound seals.
Aluminium Framed Glass Walls
Slim-line aluminium matrix framework offering industrial and contemporary grid aesthetics with structural stability for high-traffic commercial frontages and tech hubs.
Frosted & Switchable Smart Glass
Privacy glass partitions equipped with sandblasted pattern frosting, custom ceramic frit graphics, or electronic switchable smart film for instant frosted-to-clear transparency control.
Commercial Retail Frontages
Heavy-duty structural shopfront glass walls with integrated floor springs, panic hardware, and automatic entrance doors compliant with Dubai Civil Defense and mall regulations.
Technical Parameters
Material Specifications & Engineering Compliance
Detailed breakdown of system materials, hardware grade specs, and acoustic insulation values designed to meet rigorous consultant standards.
| System Feature | Technical Specification | Standards & Compliance |
|---|---|---|
| Glass Specs | 10mm, 12mm Monolithic Toughened / 13.52mm Acoustic Laminated / Double Glazed (6mm+12Ar+6mm) | BS EN 12150, ASTM C1048, EN 14449 |
| Aluminium Alloy | Extruded 6063-T6 grade architectural aluminium profiles with minimal sightlines | BS 1474, ASTM B221 |
| Surface Finish | Qualicoat Class 1 & 2 Powder Coating, Anodised (15–25 microns), PVDF Coating | ISO 2360, Qualicoat Standards |
| Acoustic Rating | Single Glazed: 32 – 36 dB | Double Glazed Acoustic: 38 – 44 dB Sound Reduction | ISO 10140-2, ASTM E90 |
| Hardware & Fittings | 316 Stainless Steel & Solid Brass locks, patch fittings, floor springs, handle pulls | EN 1154, EN 1906 (100,000+ Cycles) |
| Deflection & Safety | Designed for wind/impact resistance with structural silicone structural bonds | BS 6180, UAE Fire & Life Safety Code |
SOP Workflow
OEM / B2B Execution & Installation Process
From initial shop drawing submittals to precision jobsite sign-off, every glass partition package is handled with strict quality control.
Laser Survey & CAD Detailing
Detailed physical site elevation scanning and generation of submittal CAD shop drawings detailing glass junctions, track anchoring, and door hardware specs.
CNC Glass Machining
Automated cutting, polishing, drilling, and thermal tempering at our production facility, followed by batch quality checks and heat-soak testing.
Export Packing & Dispatch
Individual panel corner protection and heavy-duty ISPM 15 wooden crate packaging designed for safe local transport and international containerized freight.
Certified Site Installation
Mobilization of directly employed certified installers for precise profile leveling, panel setting, acoustic perimeter sealing, and functional testing.
Technical FAQ
Frequently Asked Questions on Glass Partitions
Expert insights regarding procurement, technical specifications, acoustic options, and international shipping capabilities.
We utilize 10mm to 12mm clear or low-iron tempered safety glass complying with BS EN 12150 standards. For high-acoustic requirements, double-glazed laminated acoustic glass with sound-dampening PVB interlayers is integrated into extruded aluminium track profiles.
Yes. We offer acoustic seals, double-glazing configurations providing up to 42 dB sound attenuation, frosted glass film, switchable smart glass, and integrated Venetian blinds for executive cabins and confidential boardroom spaces.
Following physical laser measurements and CAD shop drawing sign-off, precision glass tempering and profile machining take 5 to 10 working days. Site installation is systematically phased to minimize disruption to live work environments.
All safety glass panels are heat-soaked and impact-tested according to Civil Defense guidelines and Dubai Municipality standards, ensuring full compliance for commercial fit-out sign-offs.
Yes. We regularly fabricate knocked-down glass partition sets, pre-drilled hardware fittings, and custom profile tracks packaged in export-ready wooden crates for contractors and procurement managers across GCC and global markets.
Our systems incorporate heavy-duty stainless steel patch fittings, top/bottom pivot hinges, concealed floor springs, non-handed glass locks, and pull handles specifically machined during factory fabrication for a seamless flush fit.
Request a Commercial Technical Quotation
Connect directly with our engineering team for immediate BOQ estimations, CAD drawing reviews, material sample requests, and factory-direct pricing for your project.
